The Flojet RV Water System Pump is designed to provide years of satisfactory service in applications both large and small. This heavy-duty model includes a wider diameter motor with a powder-coated steel shell, cast aluminum endbells, and lower housing to improve pressure capability and life. It also includes an integrated pressure switch, vibration dampening rubber mounting feet, quick-connect ports, and an inlet strainer. A built-in bypass valve helps to reduce unwanted pump cycling and noise.
• CSA certified for potable water
• Integrated, sealed pressure switch for on-demand operation
• Internal bypass for quiet, smooth operation
• Co-molded diaphragm technology for long life and durability
• Heavy-duty model has a larger motor
• Cast aluminum lower housing allows for long-life, even at high pressures
• Can run dry without damage
• Quick-connect ports for easy installation, servicing, and maintenance
• Vibration dampening mounting feet
• Self-priming allows for versatile installation
• Built-in back flow prevention valve
• Thermal protection on motor prevents overheating
Specifications
Model: Q401V-117S-3A
Flow Rate: 4 GPM
Model Type: Heavy-Duty
Motor: Brushed, Permanent Magnet TENV
Pump Head/Upper Housing Material: Glass Fiber Reinforced Polypropylene
Diaphragm: Co-Molded TPV
Check Valves: EPDM
Voltage: 12V DC
Shutoff Pressure: 50 PSI
Max Inlet Pressure: 30 PSI
Fluid Temp Range: 32°-140°F
Max Current: 11.5 amps
Dry Self-Priming Capability: 8′
Recommended Fuse: 20A
Included Port Fittings: 2 x 1/2″ Straight Hose Barb, 1 x 1/2″ Elbow Hose Barb, 2 x 1/2″-14 NPSM Straight Threaded
Certifications: CE, RCM, CSA
Ingress Protection: IPX6
Overall: 9.4″L x 4.1″W x 3.8″H
Motor Height: 3.5″
